Product: HUAWEI Next-Generation Firewall
Model: USG6650 USG6660 USG6670 USG6680
Description: HUAWEI USG6650 USG6660 USG6670 USG6680 Next-Generation Firewall
Price:
$5,800.00 USD
Get In Touch

HUAWEI Secospace USG6000 USG6650 USG6660 USG6670 USG6680 Next-Generation Firewall USG6620 USG6630

High-Performance Security for Small Data Centers and Large or Medium-sized Enterprises

Huawei USG6650 USG6660 USG6670 USG6680 next-generation firewalls are designed for small data centers and large or medium-sized enterprises. The firewalls provide full-fledged application identification and application-layer threat and attack defense capabilities, and deliver high performane even when multiple security functions are enabled. The firewalls also offer multiple interface card slots that support various interface cards, such as GE electrical/optical and 10 GE interface cards. These cards allow users to flexibly expand services and enable the firewalls to evolve with enterprise networks, making
USG6650 USG6660 USG6670 USG6680 firewalls highly cost-effective and protecting customer investment.

USG6650 USG6660 USG6670 USG6680 Hardware Specifications  datasheet

Model USG6650 USG6660 USG6670 USG6680
Dimensions (H x W x D) mm 130.5 x 442 x 470 130.5 x 442 x 470
Form Factor/Height 3U 3U
Fixed Interfaces 2 x 10 GE (SFP+) + 8 x GE (RJ45) + 8 x GE (SFP) 4 x 10 GE (SFP+) + 16 x GE (RJ45) + 8 x GE (SFP)
USB2.0 Port 2 x USB Ports 2 x USB Ports
Expansion Slot 6 WSIC* 5 WSIC AC: 5 WSIC
DC: 3 WSIC1
Expansion I/O WSIC: 2 x 10 GE (SFP+) + 8 x GE (RJ45), 8 x GE (RJ45), 8 x GE (SFP), 4 x GE (RJ45) BYPASS
Maximum Number of Interfaces 56 x GE (RJ45) + 14 x 10GE (SFP+) + 8 x GE (SFP) or 56 x GE (SFP) + 2 x 10GE (SFP+) + 8 x GE (RJ45) 56 x GE (RJ45) + 14 x 10GE (SFP+) + 8 x GE (SFP) or 48 x GE (SFP) + 4 x 10GE (SFP+) + 16 x GE (RJ45)2
MTBF 27.07 years 23.67 years 19.18 years
Weight (Full Configuration) 24 kg 24 kg 26 kg
Local Storage Optional. Supports 300 GB or 600GB3  hard disks (RAID1 and hot-swappable).
AC Power Supply 100V to 240V, 50/60Hz
DC Power Supply NA -48V to -60V
Power Supplies Dual AC Power Supply Dual AC or dual DC power supplies
Maximum Power 350W 350W AC: 700W DC: 350W
Power Consumption (Average/Maximum) 132W/350W 152W/350W 190W/419W
Heat Dissipation 1194 BTU/h 1194 BTU/h 1429 BTU/h
Operating Environment (Temperature/Humidity) Temperature: 0°C to 45°C (without optional HDD); 5°C to 40°C (with optional HDD)
Humidity: 5% to 95% (without optional HDD), non-condensing; 5% to 90% (with optional HDD), non-condensing
Non-operating Environment Temperature: -40°C to +70°C
Humidity: 5% to 95% (without optional HDD), non-condensing; 5% to 90% (with optional HDD), non-condensing
Operating Altitude (maximum) 5,000 meters (without optional HDD); 3,000 meters (with optional HDD)
Non-operating Altitude (maximum) 5,000 meters (without optional HDD); 3,000 meters (with optional HDD)
Noise 64.2 dBA
1. With DC power input, the USG6680 supports up to three WSICs without 2XG8GE or two WSICs with 2XG8GE.
2. USG6680 (DC): 40 x GE (RJ45) + 4 × 10 GE (SFP+) + 8 × GE (SFP) or 32 x GE (SFP) + 4 x 10 GE (SFP+) + 16 x GE (RJ45).
3. The 600 GB hard disk is supported only in USG V500R001 and later versions and is not supported in USG6680 DC model.
*WISC is not hot-swappable.



USG6650 USG6660 USG6670 USG6680 Boards Datasheet Ordering Guide

Wide Service Interface Cards (WSICs) for USG6600: 2 x 10GE (SFP+), 8 x GE (RJ45)/8 x GE (SFP) 4 x GE (RJ45) BYPASS/PAC-350WD-L/SUA2MPUA

Product Model Description
USG6650 USG6650-AC USG6650 AC Host(8GE(RJ45)+8GE (SFP)+2*10GE(SFP+),
16G Memory, 2 AC Power)
USG6650-BDL USG6650-BDL-AC USG6650 AC Host(8GE(RJ45)+8GE (SFP)+2*10GE(SFP+),
16G Memory, 2 AC Power, with IPS-AV-URL Function Group Update Service Subscribe 12 Months)
USG6660 USG6660-AC USG6660 AC Host(8GE(RJ45)+8GE(SFP)+2*10GE(SFP+),
16G Memory, 2 AC Power)
USG6660-BDL USG6660-BDL-AC USG6660 AC Host(8GE(RJ45)+8GE(SFP)+2*10GE(SFP+),
16G Memory, 2 AC Power, with IPS-AV-URL Function Group Update Service Subscribe 12 Months)
USG6660 USG6660-DC USG6660 DC Host(8GE(RJ45)+8GE(SFP)+2*10GE(SFP+),
16G Memory, 2 DC Power)
USG6670 USG6670-AC USG6670 AC Host(16GE(RJ45)+8GE(SFP)+4*10GE(SFP),
16G Memory, 2 AC Power)
USG6670-BDL USG6670-BDL-AC USG6670 AC Host(16GE(RJ45)+8GE(SFP)+4*10GE(SF
P), 16G Memory, 2 AC Power, with IPS-AV-URL Function Group Update Service Subscribe 12 Months)
USG6670 USG6670-DC USG6670 DC Host(16GE(RJ45)+8GE(SFP)+4*10GE(SFP),
16G Memory, 2 DC Power)
USG6680 USG6680-AC USG6680 AC Host(16GE(RJ45)+8GE(SFP)+4*10GE(SFP+),
16G Memory, 2 AC Power)
USG6680-BDL USG6680-BDL-AC USG6680 AC Host(16GE(RJ45)+8GE(SFP)+4*10GE(SFP+),
16G Memory, 2 AC Power, with IPS-AV-URL Function Group Update Service Subscribe 12 Months)
USG6680 USG6680-DC USG6680 DC Host(16GE(RJ45)+8GE(SFP)+4*10GE(SFP+),
16G Memory, 2 DC Power)
