Firewall AntiDDoS8160 AntiDDoS8080 AntiDDoS8030  Eudemon8000E-X3 8000E-X8 8000E-X16

MPUs and SRUs
The MPU/SRU controls the system in a centralized manner and learns routing information. It is the of the system' control center.
EKEX16-FWCD00MPUB00
EKEX16-FWCD00MPUB00 is the AntiDDoS8160 MPU and is hot-swappable.
E8KE-X8-SRUA-200
E8KE-X8-SRUA-200 is the AntiDDoS8080 SRU. E8KE-X8-SRUA-200 integrates a main control unit and a switch fabric unit for data switching and is hot-swappable.
E8KE-X3-MPU
E8KE-X3-MPU is the AntiDDoS8030 MPU. It is hot-swappable.
MPUD
MPUD is the AntiDDoS8030 MPU and is hot-swappable.
EKEX16-FWCD00MPUB00
EKEX16-FWCD00MPUB00 is the AntiDDoS8160 MPU and is hot-swappable.

SFUs
SFUs are responsible for data switching between boards. The AntiDDoS8030 does not support SFUs.
E8KE-X16-SFUC-200SP
E8KE-X16-SFUC-200SP is the AntiDDoS8160 SFU. It uses non-blocking switch fabric, is hot-swappable, and is responsible for data switching of the entire system.
E8KE-X8-SFUC-200
E8KE-X8-SFUC-200 is the AntiDDoS8080 SFU. It uses non-blocking switch fabric, is hot-swappable, and is responsible for data switching of the entire system.
E8KE-X16-SFUC-200SP
E8KE-X16-SFUC-200SP is the AntiDDoS8160 SFU. It uses non-blocking switch fabric, is hot-swappable, and is responsible for data switching of the entire system.

SPUs and SPCs
SPUs are responsible for security service processing.AntiDDoS8030 Service Processing Unit (ADS-SPUC-B)
The ADS-SPUC-B motherboard applies to the AntiDDoS8030 platform. By default, this board does not have any service processing capability and must be used together with subcards. This board has two slots, and each slot can house a DDoS service card.
AntiDDoS8030 Service Processing Unit (ADS-SPUC-B2)
The ADS-SPUC-B2 is a hot-swappable motherboard that works with the AntiDDoS8030. By default, this board does not have any service processing capability and must be used together with subcards. It has one available slot that can house a DDoS service card.
AntiDDoS8080&AntiDDoS8160 Service Processing Unit (ADS-SPUD-B)
The ADS-SPUD-B motherboard applies to the AntiDDoS8080 and AntiDDoS8160 platforms. By default, this board does not have any service processing capability and must be used together with subcards. Each slot can house a DDoS service card.
Service Card (ADS-SPC-40-01)
ADS-SPC-40-01 is a subcard of the DDoS SPU and occupies a subslot on the DDoS SPU.
Service Card (ADS-SPC-60-01)
The ADS-SPC-60-01 is a single-CPU service sub-card of the anti-ddos service board, can be inserted into an SPU slot.
Service Card (ADS-SPC-80-01)
ADS-SPC-80-01 is a subcard of the DDoS SPU and occupies a subslot on the DDoS SPU.
Service Card (ADS-SPC-120-01)
The ADS-SPC-120-01 is a dual-CPU service sub-card of the anti-ddos service board, can be inserted into an SPU slot.
SPCA-APPSEC-FW
SPCA-APPSEC-FW is a single-CPU subcard of the anti-DDoS service and provides the SSL decryption function. The subcard occupies one sub-slot of the service board. The subcard can be installed on the backplane of the service board or intermixed with the anti-DDoS service subcard. Hot swap is not supported.
SPCB-APPSEC-FW
SPCB-APPSEC-FW is a dual-CPU subcard of the anti-DDoS service and provides the SSL decryption function. The subcard occupies one sub-slot of the service board. The subcard can be installed on the backplane of the service board or intermixed with the anti-DDoS service subcard. Hot swap is not supported.
AntiDDoS8030 Service Processing Unit (ADS-SPUC-B)
The ADS-SPUC-B motherboard applies to the AntiDDoS8030 platform. By default, this board does not have any service processing capability and must be used together with subcards. This board has two slots, and each slot can house a DDoS service card.
The ADS-SPUC-B is inserted into the LPU/SPU slot of the AntiDDoS8030.
The board is hot-swappable.

LPUF-240 and FPICs
The flexible LPU comprises the motherboard (LPUF-240) and multiple flexible cards (subcards), improving networking flexibility. The flexible LPU supports 240G line-rate forwarding, which reduces costs and provides customized solutions for users.

LPUF-240
The hot-swappable LPUF-240 supports 240G line-rate forwarding. It supports mixed insertion among different FPICs and has two half-width slots, each of which holds one FPIC.
6*10GE SFP+ Daughter Card (FW-6X10G-SFP+)
The FW-6X10G-SFP+ occupies one 1/2-width slot, is compatible with LPUF-240s and LPUF-120s, works in LAN or WAN mode, uses SFP+ optical modules, but is not hot-swappable.
12*10GE SFP+ Daughter Card (FW-12X10G-SFP+)
The FW-12X10G-SFP+ occupies one 1/2-width slot, is compatible with LPUF-240s and LPUF-120s, works in LAN or WAN mode, uses SFP+ optical modules, but is not hot-swappable.
3-Port 40GBase QSFP+ FPIC ()
The occupies one 1/2-width flexible card slot, is compatible with LPUF-240s and LPUF-120s, works in LAN mode, uses QSFP+ optical modules, but is not hot-swappable.
1*100GE CFP Daughter Card (FW-1X100G-CFP)
The FW-1X100G-CFP occupies one 1/2-width slot, is compatible with LPUF-240s, LPUF-120s and LPUF-101s, works in LAN mode, uses CFP optical modules, but is not hot-swappable.
5-Port 10GBase LAN/WAN-SFP+ FPIC A (E8KE-X-101-5X10GE-SFP+)
The E8KE-X-101-5X10GE-SFP+ occupies one 1/2-width flexible card slot, is compatible with LPUF-240s, LPUF-120s, and LPUF-101s, works in LAN or WAN mode, uses SFP+ optical modules, but is not hot-swappable.
24-Port 100/1000 Base-X-SFP FPIC (E8KE-X-101-24XGE-SFP)
The E8KE-X-101-24XGE-SFP occupies one 1/2-width flexible card slot, is compatible with LPUF-240s, LPUF-120s, and LPUF-101s, but is not hot-swappable.
1-Port 40GBase LAN-CFP FPIC A (E8KE-X-101-1X40GE-CFP)
The E8KE-X-101-1X40GE-CFP occupies one 1/2-width flexible card slot, is compatible with LPUF-240s, LPUF-120s, and LPUF-101s, works in LAN mode, uses CFP optical modules, but is not hot-swappable.
LPUF-240
The hot-swappable LPUF-240 supports 240G line-rate forwarding. It supports mixed insertion among different FPICs and has two half-width slots, each of which holds one FPIC.

LPUF-120 and FPICs
The flexible LPU comprises the motherboard (LPUF-120) and multiple flexible cards (subcards), improving networking flexibility. The flexible LPU supports 120G line-rate forwarding, which reduces costs and provides customized solutions for users.

LPUF-120
The hot-swappable LPUF-120 provides two 1/2-width slots, each of which holds one subcard. It supports 120G line-rate forwarding and mixed insertion among different FPICs.
6*10GE SFP+ Daughter Card (FW-6X10GE-SFP+)
The FW-6X10G-SFP+ occupies one 1/2-width flexible card slot, is compatible with LPUF-240s and LPUF-120s, works in LAN or WAN mode, uses SFP+ optical modules, but is not hot-swappable.
12*10GE SFP+ Daughter Card (FW-12X10GE-SFP+)
The FW-12X10G-SFP+ occupies one 1/2-width flexible card slot, is compatible with LPUF-240s and LPUF-120s, works in LAN or WAN mode, uses SFP+ optical modules, but is not hot-swappable.
3-Port 40GBase QSFP+ FPIC ()
The occupies one 1/2-width flexible card slot, is compatible with LPUF-240s and LPUF-120s, works in LAN mode, uses QSFP+ optical modules, but is not hot-swappable.
1*100GE CFP Daughter Card (FW-1X100GE-CFP)
The FW-1X100G-CFP occupies one 1/2-width flexible card slot, is compatible with LPUF-240s, LPUF-120s and LPUF-101s, works in LAN mode, uses CFP optical modules, but is not hot-swappable.
5-Port 10GBase LAN/WAN-SFP+ FPIC A (E8KE-X-101-5X10GE-SFP+)
The E8KE-X-101-5X10GE-SFP+ occupies one 1/2-width flexible card slot, is compatible with LPUF-240s, LPUF-120s, and LPUF-101s, works in LAN or WAN mode, uses SFP+ optical modules, but is not hot-swappable.
24-Port 100/1000 Base-X-SFP FPIC (E8KE-X-101-24XGE-SFP)
The E8KE-X-101-24XGE-SFP occupies one 1/2-width flexible card slot, is compatible with LPUF-240s, LPUF-120s, and LPUF-101s, but is not hot-swappable.
1-Port 40GBase LAN-CFP FPIC A (E8KE-X-101-1X40GE-CFP)
The E8KE-X-101-1X40GE-CFP occupies one 1/2-width flexible card slot, is compatible with LPUF-240s, LPUF-120s and LPUF-101s, works in LAN mode, uses CFP optical modules, but is not hot-swappable.
LPUF-120
The hot-swappable LPUF-120 provides two 1/2-width slots, each of which holds one subcard. It supports 120G line-rate forwarding and mixed insertion among different FPICs.

LPUF-40-A and FPIC
This section describes the structure and specifications of the Flexible Card Line Processing Unit (LPUF-40-A, 2 sub-slots) and FPIC.

LPUF-40-A
The LPUF-40-A is hot swappable and provides two 1/2-width slots, each of which holds one FPIC. It supports the following functions: 1. Forwards packets at the line speed of 40 Gbit/s. 2. Enhances networking flexibility and provides low-cost and customized solutions. 3. Supports mixed insertion between different FPICs.
20-Port 100/1000Base-X-SFP Flexible Card (P40-20xGE/FE-SFP)
The P40-20xGE/FE-SFP occupies one 1/2-width flexible card slot, is compatible with LPUF-40-A, but is not hot-swappable.
2-Port 10GBase LAN/WAN-XFP Flexible Card (P40-2x10GBase LAN/WAN-XFP)
The P40-2x10GBase LAN/WAN-XFP occupies one 1/2-width flexible card slot, is compatible with LPUF-40-A, works in LAN or WAN mode, uses XFP optical modules, but is not hot-swappable.
4-port 10GBase LAN/WAN-XFP FPIC (P40-4x10GBase LAN/WAN-XFP)
The P40-4x10GBase LAN/WAN-XFP occupies one 1/2-width flexible card slot, is compatible with LPUF-40-A, works in LAN or WAN mode, uses XFP optical modules, but is not hot-swappable.
LPUF-40-A
The LPUF-40-A is hot swappable and provides two 1/2-width slots, each of which holds one FPIC. It supports the following functions: 1. Forwards packets at the line speed of 40 Gbit/s. 2. Enhances networking flexibility and provides low-cost and customized solutions. 3. Supports mixed insertion between different FPICs.

LPUF-21 and FPIC
This section describes the structure and specifications of the Flexible Card Line Processing Unit (LPUF-21, 2 sub-slots) and FPIC.

LPUF-21
The LPUF-21 is hot-swappable and has two 1/2-width slots, each of which holds one FPIC. It supports the following functions: 1. forwarding packets at the line speed of 20 Gbit/s; 2. Networking flexibility and provisioning of low-cost and customized solutions; 3. Mixed application of different FPICs.
1-port 10GBase LAN/WAN-XFP FPIC (1 x 10GBase LAN/WAN)
The 1 x 10GBase LAN/WAN occupies one 1/2-width flexible card slot, is compatible with LPUF-21, works in LAN or WAN mode, uses XFP optical modules, but is not hot-swappable.
12-port 100Base-FX/1000Base-X-SFP FPIC (12x100/1000Base-SFP)
The 12x100/1000Base-SFP occupies one 1/2-width flexible card slot, is compatible with LPUF-21, but is not hot-swappable.
12-port 10Base-T/100Base-TX/1000Base-T-RJ45 FPIC (12x10/100/1000Base-TX-RJ45)
The 12x10/100/1000Base-TX-RJ45 occupies one 1/2-width flexible card slot, is compatible with LPUF-21, but is not hot-swappable.
1-port OC-192c/STM-64c POS-XFP FPIC (1 x OC-192c/STM-64c POS-XFP)
The 1 x OC-192c/STM-64c POS-XFP occupies one 1/2-width flexible card slot, is compatible with LPUF-21, uses 10G XFP optical modules, provides one 10 GE POS interface, but is not hot-swappable.
4-Port 10GBase WAN/LAN-XFP FPIC (4x10GBase LAN/WAN)
The 4x10GBase LAN/WAN occupies two 1/2-width flexible card slots, applies to LPUF-21, works in LAN or WAN mode, uses XFP optical modules, but does not support hot swap.
LPUF-21
The LPUF-21 is hot-swappable and has two 1/2-width slots, each of which holds one FPIC. It supports the following functions: 1. forwarding packets at the line speed of 20 Gbit/s; 2. Networking flexibility and provisioning of low-cost and customized solutions; 3. Mixed application of different FPICs.
